Hot Sale Types Of Concrete Batching Plants
Types of the Concrete Batching Plant
According to the mobility, we divide it into a stationary concrete plant, mobile concrete batch plant, and portable concrete batching plant.
AJ Series Concrete Batching Plant
AIMIX AJ series stationary concrete batching plants can be used for small or large construction that requires high accurate weighing, long project term or high-quality mass concrete production. It is also suitable for commercial concrete production and supply, large-scale engineering project construction or medium-sized concrete precast yards.
Stationary
Production Capacity
35m3/h, 50m3/h, 60m3/h, 90m3/h, 120m3/h, 180m3/h, 240m3/h
- Belt Conveyor for Aggregate Loading
- Pre-storage Bin included
- Three/Four Bins Batching Machine
- Mixer: Twin shaft mixer, Planetary
| Model | Bucket type | Belt type | |||||||
|---|---|---|---|---|---|---|---|---|---|
| AJ-25 | AJ-35 | AJ-50 | AJ-75 | AJ-60 | AJ-90 | AJ-120 | AJ-180 | AJ-240 | |
| Productivity (m³/h) | 25m³/h | 35m³/h | 50m³/h | 75m³/h | 60m³/h | 90m³/h | 120m³/h | 180m³/h | 240m³/h |
| Concrete Mixer | JS500 | JS750 | JS1000 | JS1500 | JS1000 | JS1500 | JS2000 | JS3000 | JS4000 |
| Mixer discharge capacity | 0.5m³ | 0.75m³ | 1m³ | 1.5m³ | 1m³ | 1.5m³ | 2m³ | 3m³ | 4m³ |
| Feeding Model | Lift Hopper | Belt Conveyor | |||||||
| Aggragate Batching Machine | PLD800 | PLD1200 | PLD1600 | PLD2400 | PLD1600 | PLD2400 | PLD3200 | PLD4800 | PLD6400 |
| Aggregate | 2/3/4 | 2/3/4 | 3/4 | 3/4 | 3/4/5 | 3/4/5 | 3/4/5 | 3/4/5 | 3/4/5 |
| Max. Discharging Height (m) | 3.8 | 4.1 | 4.1 | 4.1 | 4.1 | 4.1 | 4.3 | 4.3 | 4.3 |
| Installation Power (kW) | ≈65 | ≈75 | ≈100 | ≈140 | ≈110 | ≈160 | ≈220 | ≈290 | ≈340 |
| Power Supply | 380V/220V/415/440V, 50/60HZ, 3Phase | ||||||||
AJY Series Concrete Batching Plant
Mobile
Production Capacity
35m3/h, 60m3/h, 75m3/h ,90m3/h, 120m3/h
- Mixer discharge capacity: 0.5m³to 2m³
- Equipped with JS twist Shaft Mixer
- Easy to disassemble, high mobility, convenient and fast, strong site adaptability.
| Parameters/Model | AJY-25 | AJY-35 | AJY-60 | AJY-75 | AJY-90 | AJY-120 |
|---|---|---|---|---|---|---|
| Mixer | JS500 | JS750 | JS1000 | JS1500 | JS1500 | JS2000 |
| Mixer discharge capacity | 0.5m³ | 0.75m³ | 1m³ | 1.5m³ | 1.5m³ | 2m³ |
| Productivity (m³/h) | 25m³/h | 35m³/h | 60m³/h | 75m³/h | 90m³/h | 120m³/h |
| Aggregate Material Quantity (m3) | 2×6m3 | 2×8m3 | 2×10m3 | 2×10m3 | 2×12m3 | 2×12m3 |
| Discharging Height (m) | 3.8 | 3.8 | 3.8 | 3.8 | 3.8 | 3.8 |
| Weighing Accuracy | Aggregate Weighing Accuracy： ±2% | |||||
| Powder Material Weighing Accuracy：±1% | ||||||
| Water Weighing Accuracy：±1% | ||||||
| Additive Weighing Accuracy： ±1% | ||||||
| Installation Power (kW) | ≈60.8 | ≈72.3 | ≈92 | ≈102 | ≈120 | ≈160 |
| Traction Type | Semi-trailer | |||||
| Power Supply | 220V/415V/440V/380V/, 50HZ/60HZ, 3Phase | |||||
AJSY Portable Concrete Batching Plant
Small/Mini Type
Production Capacity
25m3/h
- Mixer discharge capacity: 0.5m³to 0.75m³
- Equipped with JS twist Shaft Mixer
- 1. It is almost no need for installation, which save time & labor cost in this period.
- 2. Equipped with engineering tires and lifting outrigger structures, the site can be quickly transported without disassembling and assembling equipment.
AIMIX Concrete Batching Plant Projects In Malaysia
AIMIX group has been specializing in the design, production and sale of construction equipment for many years. So far, AIMIX concrete batching plants in Malaysia have covered in these regions and cities: Penang, Kuala Lumpur, Ipoh, Kuching, Kota Kinabalu, Miri, Seberang Perai, etc.
AJY60 Mobile Concrete Batching Plant – Residential Housing Construction
- Project Time: January 25, 2025
- Mixing Capacity: 60m³/h
- Mixer Discharging Volume (L): 1000(SICOMA)
- Feeding Method: Belt type
- Cement Silo: Horizontal
- Client’s Review: AIMIX is very famous in Malaysia, has high product quality and good local service in Indonesia. Now this concrete plant is running well and the production efficiency is also very high. I am happy to recommend AIMIX to my friends.
AJ180 Stationary Concrete Batching Plant – For Commercial Concrete Production
- Mixing Capacity: 180m³/h
- Mixer: twin shaft mixer
- Mixer Discharging Volume (L): 3000
- Feeding Volume (L): 4800
- Aggregate Material Quantity (m3): 20×4
- Cement Silo (t) (optional): 4×100
- Customer’s Need: The performance of the original 90m³/h concrete plant at the customer’s site was not up to standard.
- AIMIX Solution: Provide customers with AJ-180 concrete plants with a capacity of at least 120-150 m³ per hour, dispatch engineers to supervise installation and train operators.
AJ60 Concrete Batching Plant
- Mixing Capacity: 60m³/h
- Mixer: twin shaft mixer, planetary
- Mixer Discharging Volume (L): 1000
- Feeding Volume (L): 1600
- Aggregate Material Quantity (m3): 80/60
- Cement Silo (t) (optional): 2×100
- Application Field: For Road Construction
AJ90 Concrete Batching Plant
- Mixing Capacity: 90m³/h
- Mixer: twin shaft mixer, planetary
- Mixer Discharging Volume (L): 1500
- Feeding Volume (L): 2400
- Aggregate Material Quantity (m3): 15×4
- Cement Silo (t) (optional): 3×100
- Application Field: For Commercial Concrete Production
AJSY35 Mobile Concrete Batching Plant in Penang
- Mixing Capacity: 35m³/h
- Mixer: JS750
- Feeding Way: Belt type
- Delivery Time: April, 2024
- Application Field: Self-produced concrete, easy to use.
AJ180 Concrete Batching Plant in Malaysia – Five Years in Operation
- Mixing Capacity: 180m³/h
- Mixer Model (Mixer Output L)：3000(SICOMA)
- Operation Time: Mar, 2019
- Aggregate Material Quantity (m3): 15×4
- Cement Silo (t) (optional): 4×100
- Application Field: Commercial Concrete Production and Selling.
- Customer Reviews: “I have been using this equipment for five years. Apart from some paint peeling on the exterior, there were no issues with the operation of the batching plant. AIMIX engineers in Malaysia come to the equipment site regularly to check the equipment and help us solve some minor problems. AIMIX’s service is really good.”
Main System of Concrete Batching Plant
Aggregate Batching System
Capacity: 560L- 4800L
Bins: 2bins, 3bins, 4bins, Etc
Automatic batching
Control System
Power panel and switches
Collective control terminals
Automatic control unit
Storing System
Bolted or welded
Horizontal or vertical
Storage capacity: 30T to 800T
Mixing System
Twin shaft mixer
Sicoma concrete mixer
Planetary type
Local Service in Malaysia
Provide optional Turnkey Operations both in the eastern Malaysia and the western Malaysia.
Service Team
AIMIX has setup a branch in Puchong Selangor, Malaysia and has a service team, offer you local service. Our team of service professionals provides fast, precise support thanks to an integrated relationship with engineering, sales, manufacturing and dealer personnel. Our promise lasts long after a sale and our reputation depends on our customers’ satisfaction.
Online Service
24hours online service to solve any problems.
3D Drawing
Supply free 3D drawing to plan your projects.
50+ Engineers
Send engineers to your site for instructions.
Customized Design
Professional advising for suitable model of machines.
Local Agent
Has several local agents to supply intimate service.
One Year Warranty
Warranty for any AIMIX products.
